🚀 Daffathan-Labs

Production-Grade DevOps Architecture

Daffathan-Labs is a production-ready microservices platform designed with security, automation, and zero-downtime deployment as first-class priorities.

This repository documents the architecture and infrastructure philosophy behind the system.

🏗 Architecture Overview

Internet
   │
   ▼
┌─────────────┐
│   Caddy     │  (Host Reverse Proxy)
└─────────────┘
   │
   ▼
┌─────────────────────┐
│ Internal Nginx GW   │  (Docker Network)
└─────────────────────┘
   │        │        │
   ▼        ▼        ▼
┌────┐   ┌────┐   ┌────┐
│ UI │   │ API│   │ AI │
└────┘   └────┘   └────┘

Key Principles

Only Caddy is exposed publicly.
All services bind to 127.0.0.1.
Internal Nginx handles load balancing.
Microservices live inside private Docker network.
CI/CD is fully automated.

🔐 Security Model

OS-Level Firewall (UFW)

Default policy:

sudo ufw default deny incoming
sudo ufw allow 22
sudo ufw allow 80
sudo ufw allow 443
sudo ufw enable

Docker Port Discipline

All services bind strictly to localhost:

ports:

  - "127.0.0.1:3000:3000"

This prevents Docker from bypassing UFW rules.

🔁 CI/CD Pipeline

Each microservice repository contains a GitHub Actions workflow.

Features

Automatic version detection from package.json
Branch-based tagging strategy:
- main-latest
- univ-pancasila-latest
Multi-arch build via Docker Buildx
Push to Docker Hub
Auto-deploy via SSH

Example Workflow Snippet

name: Build and Deploy

on:
  push:
    branches:

      - main

      - univ-pancasila

jobs:
  build:
    runs-on: ubuntu-latest

    steps:

      - uses: actions/checkout@v4


      - name: Set up Docker Buildx
        uses: docker/setup-buildx-action@v3


      - name: Login DockerHub
        uses: docker/login-action@v3
        with:
          username: ${{ secrets.DOCKER_USERNAME }}
          password: ${{ secrets.DOCKER_PASSWORD }}


      - name: Build and Push
        run: |
          VERSION=$(node -p "require('./package.json').version")
          docker buildx build \
            --platform linux/amd64,linux/arm64 \
            -t daffathan/api:${VERSION} \
            -t daffathan/api:main-latest \
            --push .

⚡ Zero Downtime Deployment (ZDT)

Instead of restarting containers, we use a rolling update strategy.

Deployment Script

# Scale up (create second replica)
docker compose up -d --scale api=2 --no-recreate

# Wait for service boot (NestJS / AI warmup)
sleep 20

# Scale down (remove old replica)
docker compose up -d --scale api=1

# Reload internal gateway
docker exec nginx-gateway nginx -s reload

Result

No 502 errors
No dropped connections
Seamless user experience

🧩 Internal Gateway (Nginx)

Internal Nginx handles load balancing between replicas.

Example Upstream Config

upstream api_service {
    server api:3000;
    server api:3000;
}

server {
    listen 80;

    location / {
        proxy_pass http://api_service;
    }
}

🐳 Docker Compose Structure

version: "3.9"

services:

  gateway:
    image: nginx:alpine
    container_name: nginx-gateway
    ports:

      - "127.0.0.1:8080:80"
    networks:

      - internal

  ui:
    image: daffathan/ui:main-latest
    networks:

      - internal

  api:
    image: daffathan/api:main-latest
    networks:

      - internal

  ai:
    image: daffathan/ai:main-latest
    networks:

      - internal

networks:
  internal:
    driver: bridge

🧠 Engineering Philosophy

Production-grade systems require:

Automation over manual SSH
Secure defaults
Isolation by design
Observability readiness
Deployment invisibility

This project is built on those principles.

✅ Current Guarantees

🔐 Hardened VPS with OS firewall
🐳 Private container network
🔁 Fully automated CI/CD
⚡ Zero-downtime deployments
🧩 Clean separation of concerns
🚀 Ready for scale

📌 Roadmap

Observability (Prometheus + Grafana)
Container health monitoring
Canary deployment strategy
Blue/Green deployment pipeline
Auto-scaling cluster migration

🏁 Conclusion

Daffathan-Labs is no longer a project that "just runs".

It is an infrastructure-first system designed to scale, survive, and evolve.

Deployments are boring.
Security is default.
Uptime is respected.

The foundation is ready.

Daffathan-Labs — Production-Grade DevOps Architecture
